Product Details
- Size: 1580*1066*40
- Place of Origin: Tianyuan Town, Cixi, Zhejiang 315325, China
- Brand Name: monocrystalline
- Model Number: monocrystalline220W-260W
- Weight: 21.000 kg
Maximum Power(Pmax) 220W--260W
Maximum Power Voltage(Vmp) 47.5V--48.5V
Maximum Power Current(Imp) 4.63A--5.36A
Open Circuit Voltage(Voc) 57.0V--58.2V
Short Circuit Current(Isc) 5.17A--6.00A
Maximum Efficiency 13.08%--15.45%
Maximum Power Voltage(Vmp) 47.5V--48.5V
Maximum Power Current(Imp) 4.63A--5.36A
Open Circuit Voltage(Voc) 57.0V--58.2V
Short Circuit Current(Isc) 5.17A--6.00A
Maximum Efficiency 13.08%--15.45%
Maximum System Voltage 1000VDC
Power Tolerance +(0-3)%
Operating Temperature -40 ℃ ～ +85 ℃
Standard Test Conditions(STC) Irradiance 1000W/㎡,Cell Temperature 25℃,AM1.5
- Size: 1580*1066*40
- Place of Origin: Tianyuan Town, Cixi, Zhejiang 315325, China
- Brand Name: monocrystalline
- Model Number: monocrystalline220W-260W
- Weight: 21.000 kg
